2.66 inch E-paper Display Module

型号 EPD0266B

This is a color electronic paper display module built on an active matrix TFT substrate, designed for applications requiring low power consumption and high contrast. The panel can display black, white, yellow, and red images, depending on the associated lookup table. Leveraging color e-paper display technology, this technology provides exceptional reflectivity and ultra-wide viewing angles, ensuring clear and highly readable content, even in bright environments.

产品特点

· 型号 : EPD0266B

· 尺寸: 2.66

· 分辨率: 296x152

· 显示器形状: Bar

· 接口: SPI

· 驱动IC: SSD1680

· 触摸屏: 126

+ 添加咨询

技术规格表

尺寸
2.66
inch

分辨率
296x152
Dot

型号
EPD0266B

产品类型
E-Ink

显示器形状
Bar

外形尺寸
36.3×71.82×1.0
mm

显示区域
30.704×60.088
mm

视角
All Angles

驱动IC
SSD1680

接口
SPI

工作温度
0-50℃
℃

备注
White/Black/Red

应用领域描述

产品介绍

· Pure reflective mode for low-energy usage

· Bi-stable display technology – retains image without power

· Antiglare, hard-coated front surface for durability

· Low current deep sleep mode for energy efficiency

· On-chip display RAM for efficient data storage

· Waveforms stored in on-chip OTP for easy configuration

· Serial peripheral interface available for system integration

· On-chip oscillator for stable performance

· On-chip booster and regulator control for generating VCOM, Gate, and Source driving voltage

· I2C signal master interface to read external temperature sensors

· Available in COG package for compact integration
