• Size
• 4.0
• mm

• Resolution
• 720X720
• Dot

• Model No.
• TFT0360BT11

• Product Type
• IPS

• Shape of Display
• Rectangular

• Outline Size
• 105X109.26x0.8
• mm

• Active Area
• 101.52X101.52
• mm

• View Angle
• All Angles

• Drive IC
• ST72566

• Interface
• RGB

• Touch Screen
• NA

• OP
• -30°C~+85°C
• ℃

• Remark
• For Vehicle/Industrial Control

4.0 Inch Round IPS TFT LCD Display Module 720×720 RGB Transmissive

This 4.0 inch round TFT LCD display module features a high-resolution 720 × 720 RGB pixel matrix with IPS panel technology, delivering vivid colors, wide viewing angles, and excellent image uniformity. Designed with a transmissive, normally black display mode, it ensures clear visibility and strong contrast under various lighting conditions.

The circular active area with a diameter of 101.50 mm makes this module especially suitable for modern, aesthetic-focused products where round displays are required. With an overall LCM outline diameter of 109.36 mm, the module maintains a slim and compact mechanical structure while allowing easy integration into industrial and consumer designs.

This display supports RGB interface signaling and is optimized for stable performance in embedded systems. The integrated LED backlight provides consistent brightness, while the IPS technology ensures minimal color shift even at extreme viewing angles. Operating reliably across a wide temperature range, this module is suitable for both indoor and semi-outdoor applications.

Typical use cases include smart home control panels, industrial instruments, medical devices, automotive dashboards, wearable or desktop smart terminals, and other human–machine interface applications that require a round, high-quality display. The module is manufactured in compliance with RoHS standards, ensuring environmental safety and long-term reliability.

Features

• 4.0 inch round TFT LCD with IPS technology

• 720 × 720 RGB high-resolution display

• Transmissive, normally black display mode

• Wide viewing angle with stable color performance

• Slim and compact circular LCM structure

• LED backlight with uniform brightness

• RoHS compliant design




Applications

• Smart home control panels

• Industrial control instruments

• Medical monitoring equipment

• Automotive dashboard displays

• Smart terminals and HMI devices

• Consumer electronics with round UI design




Technical Specifications
