• Size
• 3.4
• mm

• Resolution
• 192x64
• Dot

• Model No.
• HSM19264C

• Product Type
• Mono COB

• Shape of Display
• Rectangular

• Outline Size
• 130x53x12.5
• mm

• Active Area
• 104x28.9
• mm

• View Angle
• 6 o'clock

• Drive IC
• ST7920

• Interface
• Parallel

• Touch Screen
• NA

• OP
• -20°C~+70°C
• ℃

• Remark

SM19264C 192×64 STN Yellow-Green Positive Transflective LCD Module

The HSM19264C is a high-resolution 192×64 dot-matrix LCD module designed for advanced industrial and commercial devices that require clear graphical output and excellent reliability.

 Using STN Yellow-Green Positive Transflective technology, it provides strong visibility under bright ambient light while maintaining consistent contrast with LED backlighting. With 5.0 V drive voltage, a stable 1/64 duty, 1/9 bias driving configuration, and a wide temperature range of –20 °C to 70 °C, this module performs exceptionally well in harsh operating environments.

The module includes a robust metal frame, a 113.6 × 53.0 mm viewing window, and a flexible FFC interface, enabling easy integration into compact and professional systems.

Features

192 × 64 high-resolution STN Yellow-Green display

Positive transflective LCD for superior outdoor readability

Stable 1/64 duty and 1/9 bias drive method

Operates at 5.0 V with Vop = 10.5 V

Wide operating temperature range: –20 °C ~ 70 °C

High-efficiency yellow-green LED backlight (I = 510 mA)

Rugged metal frame construction for industrial reliability

FFC flexible interface for easy hardware integration

Applications

Industrial automation terminals and HMI interfaces

Medical and laboratory equipment displays

Communication control systems and base-station modules

Environmental monitoring and measurement equipment

Smart home wall panels and controller displays

Commercial vending and POS systems requiring high-resolution icons

Technical Specifications

Except the available standard LCD/TFT/OLED display products, Huaxianjing provides tailor made displays. The extensive portfolio makes it possible to create tailor-made solutions for customers to fit their application. We have the advanced display technologies available to use in your design and if there is anything you want to change about one of our existing LCD/TFT/OLED displays, we can make it happen.

With more than 15 years experience, our sales and engineering team will be with you through the entire development process and will ensure the semi or fully customization a successful display tailored made to the individual application.

Our LCD/TFT/OLED custom design solutions are available in different options according to customer requirements. Huaxianjing can offer various options on backlight type, pin and connector, cable, resistive touch screen (RTP) and projected capacitivetouch screen (CTP)  or anti-reflective or anti-glare coating, or custom cover lens, ZIF PPC or customized PCB board or a fully custom solution for your product application, as well as System Integrated Solution.
